Name: ANENG AN8802 Digital Smart Multimeter 1200A True RMS Clamp Meters AC/DC Current Tester Electric Ampere Frequency Voltmeter Tool
SKU: 862
Availability: InStock

ANENG AN8802 Digital Smart Multimeter 1200A True RMS Clamp Meters AC/DC Current Tester Electric Ampere Frequency Voltmeter Tool

ANENG AN8802

Features:

Auto/manual intervals.
True RMS measurement.
550V protection across resistance and capacitance ranges.
Large LCD screen, maximum display 6000 counts.
Sample rate: 3 times per second.
Backlight
Data retention
Polarity identification
Low voltage indicator
1200A high current measurement, low current measurement
Auto shut off
Main measurements: AC/DC voltage, AC/DC current, resistance, capacitance, diode and continuity test, temperature, frequency and duty cycle.

Specifications:

Frequency: 5/50/500/5k/50k/500k/5M/10M (±0.1+3)
Temperature: <400℃±(1.0%+5%); ≥ 400℃±(1.5%+15); <752 ℉ ±(1.0% + 5), ≥ 752 ℉ ±(1.5% + 15)
Capacity: 10nF(±5.0 + 20),100nF/1uF/10uF/100uF(±2.0% + 5),1000uF/10000uF(±5.0% +5)
DC volts: 600mV(±1.0% + 10), 6V/60V/600V/1000V(± 0.5% + 3)
AC volts: 600mV(±3.0% + 3),6V/60V/600V/750V(±1.0% +3)
ACA/DCA:600uA/6000uA(±0.8%+10),60A/600A/1200A(±2%+30)
Resistance: 600Ω(±0.5%+3),6K/60K/600K/6M(±0.5%+2),60MΩ(±1.5%+3)
Duty cycle: 1% to 99%(±1%)
Measurement mode: double integral style A/D conversion
Overrange indication: OL
Working environment: 0 ~ 40 ℃, relative humidity <80%
Power supply: 9V battery (not included)
Frequency: 1Hz to 10MHz
Temperature: -20℃ to 1000℃(-4℉ to 1832℉)
Capacity: 10pF to 6000uF
AC volts: 0.1mV to 750V
DC volts: 0.1mV to 1000V
AC current: 0.1uA to 1200A
DC current: 0.1uA to 1200A
Resistance: 0.1Ω to 60MΩ
Duty cycle: 1% to 99%
Size: approx. 238*90*45mm/9.37*3.54*1.77”

Package includes:

1 x Multimeter
2 x Test leads
1 x Temperature sensor cable
1 x Storage bag
1 x User manual
